19F high-head ring-type self-locking with light

Short Description:

`Product Model: Q19F High head.
`Material:304 stainless steel housing,PA66.
`Protection level:IP67, IK10, IP40.
`Electrical parameters:5A /250VAC.
`Contact resistance:≤50Ω.
`Insulation resistance:≥1000MΩ.
`LED voltage:3V-220V.
`Service temperature range:-20℃—55℃.
`Lamp bead life:40,000 hours.
`Mechanical life:30 times/min,500,000 times.


  • :
  • Product Detail

    FAQ

    Product Tags

    Product Characteristics Q19F High head

    Using flame retardant material, stainless steel shell anticorrosion and dustproof, silicone waterproof ring, high performance, solid and reliable, safety guarantee.

    Product Drawing

    asd
    sd

    Application Areas Q19F High head

    1. Industrial use: Q19F High head products are widely used in industrial fields, such as industrial cooling, circulating water treatment, water supply of high-rise buildings, water pressure increase transmission and industrial cooling system.

    2. Agricultural uses: Agricultural uses are mainly used in field irrigation, drainage, aquaculture and fisheries scenarios.

    3. Life use: Q19F High head products are also widely used in life scenes, such as household tap water supply, seawater desalination, pool circulating water treatment, etc.

    To sum up, Q19F High head products are mainly used in the field of pumps, suitable for a variety of scenarios requiring high water pressure or hydraulic pressure.

    Package picture

    asd
    asd
